CM212 2 Group 12 Channels Input Mixer with Rach Mounted
DSPPA

CM212 2 Group 12 Channels Input Mixer with Rach Mounted

The CM208/CM212/CM216/CM224 8/12/16/24-channel professional mixing console is a high-performance mixer designed to meet the needs of audio professionals, music producers and performers. There are 4/8/12/20-channel XLR mono input optional and 2-channel stereo input. The series of devices features 48V phantom power, a 24 DSP effects processor, USB recording, and an LED status screen, offering precision with 3-band EQ, mute and PFL switches on each channel, which achieves a new level of audio mixing, providing excellent sound quality and flexible control.
PriceRs. 82,500 per unit · excl. VAT

Supply price in NPR. Delivery, structure, processor, installation and VAT are itemised in your quote; project pricing available.

Request itemised quote Ask on WhatsApp
Official warranty Installed by our engineers Spares in Kathmandu
Specifications

Spec sheet

Datasheet (PDF)
Display 1
Crosstalk (1kHz)-70dB among each input channel; -70dB among input/output channels (CH INPUT)
Electrical 5
Frequency Characteristics (MAIN OUT)20Hz–20kHz (+1dB, -3dB @ +4dBu, 600Ω, gain control at minimum)
Channel Input Equalization±15dB (HIGH: 10kHz, MID: 2.5kHz, LOW: 100Hz)
Mono/Stereo Input Peak IndicatorRed indicator lights when post-EQ signal reaches within 3dB of clipping level
Phantom Power (+48V)Switchable +48V Phantom Power for Balanced Inputs
Power Consumption51W
Mechanical 4
Package Dimensions (L×W×H)520 × 175 × 490 mm
Product Dimensions (L×W×H)460 × 400 × 135 mm
Gross Weight6.5 kg
Net Weight5.4 kg
Other 4
Total Harmonic Distortion (MAIN OUT)0.1% (THD+N) @ +4dBu, 20Hz–20kHz, 600Ω (gain control at maximum)
Hum & Noise-128dBu Equivalent Input Noise (CH 1–8)-100dBu Residual Output Noise (ST OUT)-88dBu (92dB S/N) ST & GROUP Main Attenuator at nominal level-81dBu (85dB S/N) AUX & EFFECT Main Control at nominal level-64dBu (68dB S/N) ST & GROUP Main Attenuator and Channel Attenuator at nominal level
Graphical Equalizer Variation±12dB, 7 Bands (125, 250, 500, 1k, 2k, 4k, 8k Hz)
Internal Digital Effect16 Effect Programs with Parameter Control
