Product Images
Huidu HD-WF4 Control Card
₨ 2,200.00
The Huidu HD-WF4 is a compact and cost-effective Wi-Fi control card designed for single and dual-color LED displays. Equipped with four HUB75E interfaces, it supports full-color modules and is compatible with both standard and ICN2038S chips. The card offers a maximum control range of 768×128 pixels, making it suitable for applications such as storefront signs, vehicle-mounted displays, and door lintels.
Description
Huidu HD-WF4
| Function | Parameters |
| Support Module | Support HUB75 port full color module, support normal and ICN2038 IC |
| Scan mode | Support static to 1/32S |
| Control range | 768*128, Widest 1280, Highest 256 |
| Communication Port | Wi-Fi, U-Disk |
| FLASH Capacity | 8M Byte |
| Support RGB | Full-color module can display red, green, blue, yellow, Purple, green, white |
| Gray level | 8 level, support full color text |
| Program Quantity | 999 programs, support switch the program by wifi remote |
| Area Quantity | 20 pcs areas with separate zone and separate special effects and border |
| Display Showing | Text、Animated word、3D Word、Image & Text(Picture, SWF), Excel, Time, Temperature, Timing, Count, Lunar calendar |
| Automatic switch screen | Support timer switch machine |
| Dimming | Support brightness setting, time period brightness setting |
| Power supply | Micro USB, standard 5V |
| Certification | CE、FCC、RoHS |
